LP20 12-Pin 5A Signal Flange Mount Waterproof Connector - Metal Shell, Plastic Interface, Solder Terminals

全カテゴリー

電源プラグ

送信

Mr. Nick Zou

nick@cableinco.com

+86 13310837463

今接触

LP20 12-Pin 5A Signal Flange Mount Waterproof Connector - Metal Shell, Plastic Interface, Solder Terminals

ブランド名:	Cablein
MOQ:	100pcs
価格:	The price ranges from $1 to $4 USD per pieces
パッケージの詳細:	高品質の輸出カートン
支払条件:	T/T、ウェスタンユニオン

詳細情報

製品の説明

詳細情報

起源の場所:

深Shenzhen China

証明:

CE, ROHS, TUV , ETL

防水:

IP67

住宅資料:

ナイロン

アセンブリワイヤー:

はんだ付けするか、またはねじ付属品

火炎抵抗の評価:

UL94 V-0

動作温度:

-40°C〜85°C

色:

黒

保証:

2年

温度範囲:

-40〜105°C

製品の説明

LP20 12-Pin 5A Signal Flange Mount Waterproof Connector - Metal Shell, Plastic Interface, Solder Terminals

Specifications

Pin: 12 Pin
Current Rating(A): 5A Max
Material: Metal+plastic
Conenction Way: Push-button snap fastener
Operating Voltage: 250V Max
Assembly Wire: IP-Rated Locking Gland
Mounting Type: Flange Mounting Type
Out Door UV Resistance: Pass
Cable Jacket OD: 0.34-0.75 mm²

Datasheet

Pins Number	2Pins	5Pins	9Pins
Rated Voltage	500V		250V
Rated Current	20A	10A	5A
Insulation voltage	2.5KV	1.5KV
IP CODE	IP68
Cable Jacket OD	Standard Power:⌀8-12mm Standard Signal:⌀5-6.5mm Other:⌀5-9mm
Assembly cable diameter	2.4-4mm²/14-12AWG	1-1.5mm²/18-16AWG	0.34-0.75mm²/22-20AWG
Ambient temperature	-40℃~+80℃

Advantages

Material & Performance:
The housing is made of high-performance PBT engineering plastic, ensuring stable electrical properties, excellent heat resistance, and corrosion resistance. The gold-plated conductive components guarantee superior conductivity and meet temperature rise requirements even in high-temperature environments.
Secure Locking Mechanism:
Features a push-to-lock snap-fit design for secure mating and smooth insertion/removal.
Waterproof Design:
Standard IP67 rating (IP68 optional) provides precise waterproof protection.
Certifications & Compliance:
Complies with TUV, ISO, CE, and RoHS certifications, meeting global market requirements.

Application Industries

Automation Equipment
LED Lighting
Security Equipment
Telecommunication Equipment
New Energy
Electronic Devies

Drawing

FAQ

Q: What are the typical applications for this flange mount connector?

A: The LP20 flange mount connector is ideal for industrial control systems, outdoor telecommunications equipment, heavy machinery, and marine electronics where secure panel mounting and environmental protection are required. Its 12-pin configuration and 5A rating make it suitable for power distribution and signal transmission in demanding conditions.

Q: How does the metal-plastic hybrid design enhance performance?

A: The stainless steel metal shell provides electromagnetic shielding (EMI/RFI protection), mechanical robustness, and corrosion resistance, while the plastic interface ensures electrical insulation and weight reduction. This combination delivers optimal protection against both physical stress and environmental factors.

Q: What waterproof rating does this connector achieve?

A: When properly installed with the included sealing gasket, the connector achieves IP68 rating, meaning it is dust-tight and can withstand continuous submersion in water up to 1.5 meters depth for 30 minutes. The solder terminals further prevent moisture ingress through secure, sealed connections.
